Introduction What is SPCD Steels? SPCD steels are drawing quality cold rolled steels, which are consumed for drawing applications.
Dimensional Characteristics of SPCD Steels: The applicable thickness for this SPCD material as defined in the JIS 3141 starts from 0.25 mm to 2.5 mm. However the width of SPCD material ranges to 2000 mm. The Chemical Composition of SPCD Steels: JIS G 3141 defines the chemical composition of SPCD steels as under:
SPCD is one of the popular cold rolled steel.Features of cold-rolled steel plate:
1, cold rolled steel plate thickness more accurate, smooth surface, beautiful, but also has superior mechanical properties, especially machining performance.
2. The maximum thickness of cold-rolled steel plate is less than 0.1-- 8.0mm, such as the thickness of cold-rolled steel plate in most factories is less than 4.5mm;The minimum thickness and width are determined according to the equipment capacity and market demand of each plant.
3, cold rolled steel mill power, low rolling efficiency, and the rolling process in order to eliminate the work hardening have to carry out intermediate annealing, so the cost is higher, but cold rolled steel surface bright, good quality, can be used to process finished products, cold rolled steel is widely used.
Specification
|
Product Name |
SPCD Cold Rolled Steel Coil |
|
Standard |
JIS |
|
Grade |
SPCC, SPCD, SPCE |
|
Width |
600-1500mm Or As Buyer’s Requirement |
|
Thickness |
0.12-3mm |
|
Coil Weight |
3-14 MT |
|
Steel Coil Internal Diameter |
508mm/610mm |
|
Technique |
Cold Rolled |
|
Tolerance |
As The Standard Or As Required |
|
Application |
Household Appliance, Automobile, Machine Etc. |
|
MOQ |
25 MT |
|
Packing Details |
Standard Seaworthy Export Packing Or As Required |
|
Delivery |
Within 15 To 90 Days, According To Order Quantity |
|
Payment |
T/T Or L/C |
Technical Data SPCD is the grade under Japan steel (JIS standard series) of a steel grades and it equivalent to China's high-quality carbon structural steel 08 al (13237).
SPCD name
S (Steel) means Steel.
P means Plate
C means cold rolled
D means drawing
SPCD main use for Stamping and drawing purposes, it locals between (SPCC) and SPCE, if it does not involve drawing stamping can choose (SPCC), if deep pumping can use the SPCE. If it in between SPCC and SPCE,it can use SPCD .
For the SPCD cold rolling steel and strip specification lists, the thickness of 0.3-3.5 mm and width from 120-1850mm are all available by our company. For the length, we can also offer as your requirements. The more information of SPCD steel shown in the following table:
SPCD steel chemical composition
|
Grade |
C |
Mn |
P |
S |
|
SPCD |
≤0.12 |
≤0.50 |
≤0.040 |
≤0.040 |
SPCD Mechanical Properties
|
STEEL GRADE |
Tensile Strength N/mm (min) |
Yield Strength N/mm (Max) |
Elongation min. |
||||||
|
thickness |
>0.25 |
>0.25 |
0.25-0.30 |
0.3-0.4 |
0.4-0.6 |
0.6-1.0 |
1.0-1.6 |
1.6-2.5 |
>2.5 |
|
SPCD |
270 |
240 |
30 |
33 |
36 |
38 |
39 |
40 |
41 |
