Prepainted Steel Coils Pre-painted Hot Galvanized Coil

The Prepainted Steel Coils Pre-painted Hot Galvanized Coil is a material that is obtained by subjection to chemical treatment (coating) followed by reheating and cured by a hot-dipped galvanized C...
Rated 4.9/5 based on 469 customer reviews
Share:
Content
The Prepainted Steel Coils Pre-painted Hot Galvanized Coil is a material that is obtained by subjection to chemical treatment (coating) followed by reheating and cured by a hot-dipped galvanized Coil of aluminum. A hot-dip zinc-coated thin-film sheet of  Prepainted Steel Coils Pre-painted Hot Galvanized Coil is also known as the pre-painted galvanized steel coil and color coated steel coil.
Prepainted Steel Coils Pre-painted Hot Galvanized Coil Description
Product Name
Prepainted Steel Coils Pre-painted Hot Galvanized Coil
Spangle
Small/ Regular/ Big/ Zero(no)
Technical Standard
EN10147/EN10142/DIN 17162/JIS G3302/ASTM A653
Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD , S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80
(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type
Coil
Thickness
0.12-6.00mm,or customer’s requirement
Width
600mm-1500mm,according to customer’s requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)/Electro-Galvanised Steel(EGI)
Zinc Coating
20-275g/m2
Surface Treatment
Passivation(C),Oiling(O),Lacquer sealing(L),Phosphating(P),Untreated(U)
Surface Structure
Normal spangle coating(NS),minimized spangle coating(MS),spangle-free(FS)
Quality
Approved by SGS,ISO
ID
508mm/610mm,according to customer’s requirement
