HDGI 0.2mm Thickness Galvanized Steel Coil

Material: ASTM A653, DX51D, Q195
Product name: Galvanized Steel Coil Cold rolled steel Metal roofing sheet steel coil
Thickness: 0.13-0.8 mm
Zinc Coating: 20-120g/m2

Cold Rolled Galvanized Steel Strip Coil products are mainly used in construction, light industry, automobile, agriculture, animal husbandry and fishery and commerce industries. Among them, the construction industry is mainly used to manufacture anti-corrosion industrial and civil building roof panels, roof grilles, etc.

Coils are divided into chilled coils and cold rolled coils. The difference between the two is that in appearance, the general chilled coil is slightly black; the surface quality, structure, and dimensional accuracy of the cold-rolled sheet are better than that of the chilled coil; in terms of performance, because the hot-rolled coil goes through the cold rolling process The directly obtained chilled coils undergo work hardening during cold rolling, resulting in an increase in yield strength and some residual internal stress, and the external performance is relatively “hard”, so it is called chilled coils.

Coils are divided into chilled coils and cold rolled coils. The difference between the two is that in appearance, the general chilled coil is slightly black; the surface quality, structure, and dimensional accuracy of the cold-rolled sheet are better than that of the chilled coil; in terms of performance, because the hot-rolled coil goes through the cold rolling process The directly obtained chilled coils undergo work hardening during cold rolling, resulting in an increase in yield strength and some residual internal stress, and the external performance is relatively “hard”, so it is called chilled coils.

Cold-rolled coil refers to a steel strip that is directly rolled into a certain thickness with a roll at room temperature and rolled into a whole coil with a coiler. Compared with hot-rolled coils, cold-rolled coils have a brighter surface and higher finish, but will generate more internal stress and are often annealed after cold-rolling.

Galvanized steel coil, also known as galvanized coil, is a galvanized coil product. Galvanized coil, a steel material coated with zinc. The galvanized coil is the predecessor of the galvanized sheet. The galvanized coil is cut into sheets by equipment. The galvanized coil is placed on the shelf with a forklift or aerial crane, and then transferred, flattened and cut by the equipment.

Cold-rolled steel coils have good properties, and cold-rolled strips and steel sheets with thinner thickness and higher precision can be obtained by cold-rolling. High flatness, high surface finish, clean and bright surface of cold-rolled sheet. It is easy to be coated and processed and has the characteristics of high stamping performance and low yield point, so cold-rolled steel coil has a wide range of uses, mainly used in automobiles and building materials. At the same time, it is also the substrate for the production of galvanized steel sheets in coil and galvalume steel coil.

Galvanized refers to a surface treatment technology that coats a layer of zinc on the surface of metals, alloys or other materials for aesthetics and rust prevention. The main methods used are hot-dip galvanizing and electro-galvanizing. It prevents corrosion of steel, and its protective performance is closely related to the thickness of the coating.

Cold coil is made of hot rolled coil at room temperature and below the recrystallization temperature, including plate and coil, of which the sheet delivered is called steel plate, also known as box plate or plate; the long length and delivered in coil is called steel strip, also known as coil plate.

Cold-rolled steel coil is better in surface quality (such as Surface roughness) than hot plate because it is obtained by cold rolling and some surface finishing is carried out at the same time. Therefore, if the product after the sequence of painting, such as coating quality, there are higher requirements, the general choice of the cold plate.

Cold-rolled coils are widely used, such as automobile manufacturing, electrical products, rolling stock, aviation, precision instruments, canned food, etc. Cold-rolled sheet is the abbreviation of ordinary carbon structural steel cold-rolled sheet, also known as cold-rolled sheet, commonly known as cold-rolled sheet, and sometimes mistakenly written as cold-rolled sheet. The cold plate is a hot-rolled steel strip of ordinary carbon structural steel, which is further cold-rolled into a steel plate with a thickness of less than 4mm.
